RIDGELINE / MATERIAL STUDY 01

Inside the bend.

Inside
the bend.

The strength of steel.
The freedom to take another path.

316LSTAINLESS STEELP1MECHANICAL FITTING
01 / FORMCORRUGATED STAINLESS STEEL + BRASS
VISUAL STUDY / ILLUSTRATIVE INTERNAL GEOMETRY

RIDGELINE / INSIDE THE BEND

Steel. Brass.
A different perspective.

A photographic reference-led 3D study of corrugated 316L stainless steel and the P1 mechanical fitting.

Explore the outer form, separate the fitting components, or reveal a conceptual flow animation.

A visual study

Internal geometry, the O-ring position and threads are illustrative. This is not manufacturer CAD or installation guidance. Final self-flare deformation is not simulated. The teal flow is an artistic visualisation, not a fluid dynamics result.

Real-time 3D · Original sound design · Ridgeline 2026 identity
